PA10 is a time attendance and access control terminal with Palm & Fingerprint Hybrid Biometrics. The Palm verification includes Palm Print & Palm Vein, so it not only is touchless, but also supports anti-spoof function. The Z-ID sensor possesses outstandingly high identification rate towards dry, wet and rough fingers. TCP/IP, RS485, PoE (optional) and Wi-fi (optional) are also available which enable PA10 to be applied in different networks and various situations.
- Display2.4-inch TFT LCD Color Screen
- Palm Capacity1,000
- Fingerprint Capacity (optional)3,000
- Transaction Capacity150,000
- SensorZ-ID Sensor
- CommunicationRS485, TCP/IP, USB-host, Wi-fi (Optional)
- Access Control Interface3rd Party Electric Lock, Door Sensor, Exit Button, Alarm, Doorbell
- Wiegand SignalInput, Output, SRB
- Aux. Input1ea for linkage function
- FunctionsDST, Automatic Status Switch, Anti-passback, Scheduled-Bell, Printer (Optional), External FP Reader, ADMS (Optional), PoE (Optional)
- Power Supply12V DC 3A
- Operating Temperature0 °C - 45 °C
- Operating Humidity20% - 80%
- SDK and SoftwareStandalone SDK, ZKBio Access software
